Bhavesh Steel is a reliable name as manufacturers and suppliers of good quality fasteners, with specialization in Alloy Steel Gr 8.8 Bolts all over Dubai, UAE. We are known for our excellence and present precision-crafted bolts that are as per international standards and fulfill diverse industrial applications. Our products are formulated for maximum strength, endurance, and resistance to corrosion. Having a well-developed supply chain and decades of experience, Bhavesh Steel provides guaranteed delivery and unparalleled quality control. We cater to a wide range of customers across industries like construction, engineering, automotive, and oil & gas sectors in the UAE and internationally.
Alloy Steel Gr 8.8 Bolts consist mainly of medium carbon steel and are frequently quenched and tempered for enhanced strength. Their common chemical constitution consists of carbon (0.25–0.55%), manganese (0.6–1.7%), and minor elements such as phosphorus and sulfur. They provide tensile strength of approximately 800 MPa and yield strength of 640 MPa, which is appropriate for high-stress applications. They have also good hardness and wear resistance. Heat treatment improves their mechanical properties, guaranteeing reliability and performance in harsh conditions.
| AStm Standards | DIN ISO EN 4017 & 4014 DIN 933 / 931 & IS 1363 / 1363 |
| Size | Diameter 20 to 100 Milimeter / Inch 3/4 to 3.1/2 |
| Surface Finish | Zinc plated / Plain / Hot dip galvanised |
| CLASS | MATERIAL AND TREATMENT | C | C | P | S | B | TEMPERING TEMP. [C] |
|---|---|---|---|---|---|---|---|
| MIN | MAX | MAX | MAX | MAX | |||
| 8.8 | CARBON STEEL WITH ADDITIVES (E.G. B, MN OR CR) QUENCHED AND TEMPERED | 0.15 (D) | 0.4 | 0.025 | 0.025 | 0.003 | 425 |
| CARBON STEEL QUENCHED AND TEMPERED | 0.25 | 0.55 | 0.035 | 0.025 |
| Grades | Size Range | PS [MPa] | YS (min) [MPa] | TS (min) [MPa] | Hardness [Rockwell] |
|---|---|---|---|---|---|
| Class 8.8 | Under M16 | 580 | 640 | 800 | |
| 17-72 | 600 | 660 | 830 | C23–34 |
| Bolt Dia | Body Dia | Head Dia(F) | Head Height (H) | Degree of Slope | |||
|---|---|---|---|---|---|---|---|
| (D) | Max | Max Edge Sharp | Min Edge Sharp | Absolute Min Rounded | Max | Min | Â |
| 1/2 | 0.515 | 0.935 | 0.905 | 0.845 | 0.269 | 0.233 | 78° to 82° |
| 5/8 | 0.642 | 1.169 | 1.132 | 1.066 | 0.336 | 0.292 | 78° to 82° |
| 3/4 | 0.768 | 1.402 | 1.357 | 1.285 | 0.403 | 0.349 | 78° to 82° |
| 7/8 | 0.895 | 1.637 | 1.584 | 1.511 | 0.47 | 0.408 | 78° to 82° |
| 1 | 1.022 | 1.869 | 1.81 | 1.735 | 0.537 | 0.466 | 78° to 82° |
| 1-1/8 | 1.149 | 2.104 | 2.037 | 1.962 | 0.604 | 0.525 | 78° to 82° |
| 1-1/4 | 1.277 | 2.337 | 2.262 | 2.187 | 0.671 | 0.582 | 78° to 82° |
| 1-3/8 | 1.404 | 2.571 | 2.489 | 2.414 | 0.738 | 0.641 | 78° to 82° |
| 1-1/2 | 1.531 | 2.804 | 2.715 | 2.64 | 0.805 | 0.698 | 78° to 82° |
| Dimensions per ASME B18.5 1990 (R 1998) | |||||||
| Diameter Chart | M4 | M5 | M6 | M8 | M10 | M12 | M14 | M16 | M18 | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 | M52 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pitch List | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 | ||||||||
| GR A Length | 40 | 50 | 60 | 80 | 100 | 120 | 140 | 150 | Grade A not applicable to these dia’s | ||||||||||||
Head Across Flat (S) Nom = Max Min GR A GR B | 7 | 8 | 10 | 13 | 16 | 18 | 21 | 24 | 27 | 30 | 34 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | 75 | 80 |
| 6.78 | 7.78 | 9.78 | 12.73 | 15.73 | 17.73 | 20.67 | 23.67 | 26.67 | 29.67 | 33.38 | 35.38 | GR A not applicable to these diameters | |||||||||
| 6.64 | 7.64 | 9.64 | 12.57 | 15.57 | 17.57 | 20.16 | 23.16 | 26.16 | 29.16 | 33 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.1 | 68.1 | 73.1 | 78.1 | |
Head Height Nom Tol + or – GR A GR B | 2.8 | 3.5 | 4 | 5.3 | 6.4 | 7.5 | 8.8 | 10 | 11.5 | 12.5 | 14 | 15 | 17 | 18.7 | 21 | 22.5 | 25 | 26 | 28 | 30 | 33 |
| 0.125 | 0.15 | 0.18 | 0.215 | GR A not applicable to these diameters | |||||||||||||||||
| 0.2 | 0.24 | 0.29 | 0.35 | 0.42 | 0.5 | ||||||||||||||||
Across corners e Min GR A GR B | 7.66 | 8.79 | 11.05 | 14.38 | 17.77 | 20.03 | 23.36 | 26.75 | 30.14 | 33.53 | 37.72 | 39.98 | GR A not applicable to these diameters | ||||||||
| 7.5 | 8.63 | 10.89 | 14.2 | 17.59 | 19.85 | 22.78 | 26.17 | 29.56 | 32.95 | 37.29 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 71.3 | 76.95 | 82.6 | 88.25 | |
Thread Length (b) For lengths < or = 125ilimeter For lengths > 12ilimeter <= 200milimeter For lengths > 200ilimeter | 14 | 16 | 18 | 22 | 26 | 30 | 34 | 38 | 42 | 46 | 50 | 54 | 60 | 66 | Not specified as full thread recommended | ||||||
| 20 | 22 | 24 | 28 | 32 | 36 | 40 | 44 | 48 | 52 | 56 | 60 | 66 | 72 | 78 | 84 | 90 | 96 | 102 | 108 | 116 | |
| 33 | 35 | 37 | 41 | 45 | 49 | 53 | 57 | 61 | 65 | 69 | 73 | 79 | 85 | 91 | 97 | 103 | 109 | 115 | 121 | 129 | |
| Major Diameter at thread (minimum) | 3.838 | 4.826 | 5.794 | 7.76 | 9.732 | 11.701 | 13.682 | 15.682 | 17.623 | 19.623 | 21.623 | 23.577 | 26.577 | 29.522 | 32.522 | 35.465 | 38.465 | 41.437 | 44.437 | 47.399 | 51.399 |
| Major Dia at thread (maximum) | 3.978 | 4.976 | 5.974 | 7.972 | 9.968 | 11.966 | 13.962 | 15.962 | 17.958 | ||||||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Alloy Steel Gr 8.8 Bolts in Dubai, UAE. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your Alloy Steel Gr 8.8 Bolts needs!
Alloy Steel Gr 8.8 Bolts find their applications in various industries where high-strength bolting solutions are needed. They form a critical part of the construction industry, particularly for steel frames, bridges, and high-rise buildings because of the load-carrying capacity. In the automotive and heavy machinery industries, they are used to deliver secure connections in engine components, chassis, and gear systems. They are also applied on oil & gas platforms, pipelines, and refineries, where mechanical stress and environmental resistance is paramount. Their toughness and durability make them a popular option for reliability in applications requiring dynamic and static loads.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
