Bhavesh Steel is a well-known Alloy Steel T23 Tubing manufacturer and supplier, established in Dubai, UAE. With a reputation for delivering quality and precision-engineered products, Bhavesh Steel addresses various industrial segments by offering high–quality tubing solutions. With its state-of-the-art manufacturing facilities and expert team, the company guarantees that every product complies with international standards. Alloy Steel T23 Tubing is particularly preferred for its exceptional strength, corrosion resistance, and durability in high-temperature environments. Bhavesh Steel remains a respected name, providing consistent and affordable solutions to customers in the Middle East and the world at large.
Alloy Steel T23 Tubing contains chromium, molybdenum, tungsten, vanadium, and trace amounts of carbon, which increases its high-temperature strength and oxidation resistance. Its conventional mechanical properties are tensile strength between 440–590 MPa and yield strength of 290 MPa. The alloy has high creep resistance and fair weldability and, therefore, finds application in high-pressure service. With a hardness of about 190 HB, T23 tubing is constructed to endure adverse operating conditions without compromising structure and long life of service in aggressive industrial processes.
| SA213 T23 Tube Standard | ASTM A213 T23, SA213 T23 (with IBR Test Certificate) |
|---|---|
| SA213 T23 Tube Specifications | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/90/PartII/620 & 622 DIN/17175/13CrMo44 DIN/17175/10CrMo910 DIN/17175/15Mo3 |
| SA213 T23 Tube Size | 6.35 mm OD to 101.6 mm OD |
| Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| SA213 T23 Tube Thickness | 3-12mm |
| SA213 T23 Tube Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T23 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| Craft | Cold rolled and Cold drawn |
| SA213 T23 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T23 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| SA213 T23 Tube Length | Standard Double & In Cut length also. |
| SA213 T23 Tube End | Plain End, Beveled End, Treaded |
| Specialized in | ASME SA213 T23 Boiler Tube, SA213 T23 Heater Tube, SA213 T23 Heat Exchanger Tube |
| SA213 gr T23 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| SA213 grade T23 Tube Application | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| T23 | 0.04~0.10 | 0.1~0.6 | 0.03max | 0.01 max | 0.5 max | 0.05~0.30 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T23 | 510 min | 400 min | 20 min | 220 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T23 Tubing in Dubai, UAE. We offer premium steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to timely delivery and exceptional customer service, we utilize only the finest raw materials to ensure superior performance in industrial applications with demanding specifications. Contact us today for all your Alloy Steel T23 Tubing needs!
Alloy Steel T23 Tube is commonly applied in high-pressure and high-temperature settings, especially in refineries, petrochemical plants, and power plants. Its outstanding thermal stability and toughness suit it for boiler tubes, heat exchangers, reheater tubes, and superheaters in fossil fuel and nuclear power plants. The tube is applied in pressure vessels and steam piping because of its creep deformation and durability. Due to its superior mechanical characteristics, Alloy Steel T23 is a choice of first preference for applications requiring serious performance, safety, longevity, and reliability under adverse conditions, ensuring operational effectiveness and dependability.
