Bhavesh Steel is a prominent alloy steel T5 tubing manufacturer and supplier company based in Dubai, UAE, supplying top-notch products to customers in the Middle East as well as around the world. Committed to excellence, we supply tubing solutions that conform to global standards and service diverse industrial needs. Our Alloy Steel T5 Tubes are built for toughness, better corrosion resistance, and consistent performance in harsh high-temperature and high-pressure conditions. Through superior manufacturing facilities and customer-centric approach, Bhavesh Steel has emerged as a name of reliability in supplying precision-engineered tubing solutions.
Alloy Steel T5 Tubing is made up of chromium (4-6%), molybdenum (0.45-0.65%), manganese, and carbon that combined provide superior strength, corrosion resistance, and high-temperature stability. The tubing has very good mechanical properties with a minimum tensile strength of 415 MPa, yield strength of 205 MPa, and excellent elongation and hardness. It is well suited to withstand high-pressure and high-heat applications. The tubing is typically normalized and tempered in order to develop a very fine balance of toughness, ductility, and durability in harsh industrial conditions.
| SA213 T5 Tube Standard | ASTM A213 T5, SA213 T5 (with IBR Test Certificate) |
|---|---|
| SA213 T5 Tube Specifications | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/90/PartII/620 & 622 DIN/17175/13CrMo44 DIN/17175/10CrMo910 DIN/17175/15Mo3 |
| SA213 T5 Tube Size | 6.35 mm OD to 101.6 mm OD |
| Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| SA213 T5 Tube Thickness | 3-12mm |
| SA213 T5 Tube Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T5 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| Craft | Cold rolled and Cold drawn |
| SA213 T5 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T5 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| SA213 T5 Tube Length | Standard Double & In Cut length also. |
| SA213 T5 Tube End | Plain End, Beveled End, Treaded |
| Specialized in | ASME SA213 T5 Boiler Tube, SA213 T5 Heater Tube, SA213 T5 Heat Exchanger Tube |
| SA213 gr T5 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| SA213 grade T5 Tube Application | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| T5 | 0.15 | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5b | 0.15 max | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5c | 0.12 max | 0.30~0.60 | 0.025 max | 0.025 max | 0.50 max | 0.45~0.65 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T5 | 415 min | 205 min | 30 min | 179 max |
| T5b | 415 min | 205 min | 30 min | 179 max |
| T5c | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T5 Tubing in Dubai, UAE. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T5 Tubing needs!
Alloy Steel T5 Tubing finds application in numerous industries because it is strong and thermally stable. It is particularly being used for power plant applications, oil and gas refineries, chemical processing plants, and petrochemical facilities. Typical applications are heat exchangers, boilers, superheaters, and reheater tubes, wherein the material has to withstand intense heat and pressure. Its corrosion- and oxidation-resistance at high temperatures further qualifies it for application in aerospace, industrial furnaces, and mechanical equipment calling for durable, high-performance tubing.
