Bhavesh Steel is a top-grade manufacturer and supplier of Carbon Steel A334 Grade 9 Tubing in Dubai, UAE. As a specialty manufacturer of high-strength, low-alloy steel products, we deal with industries that need materials performing consistently at low temperatures. Our A334 Grade 9 tubes are acquired from quality mills and go through thorough quality control processes to guarantee that they are international standard. Whether you require standard sizes or customized specifications, Bhavesh Steel is your one-stop solution for reliable and long-lasting carbon steel tubing solutions in the UAE.
A334 Grade 9 is a high-strength, low-alloy carbon steel with 1.60–2.24% nickel. It has a composition with a maximum of 0.20% carbon, 0.40–1.06% manganese, and up to 0.50% silicon. This grade provides at least tensile strength of 450 MPa and at least yield strength of 240 MPa. These mechanical properties qualify A334 Grade 9 tubing for use in applications demanding high strength and effective resistance to corrosion and oxidation. The composition of the steel makes it perform under low-temperature conditions.
| Element | A/SA 334 Gr A9 |
| C | 0.30 max |
| Mn | 0.40-1.06 |
| P | 0.025 max |
| S | 0.025 max |
| Element | A/SA 334 |
| Tensile Strength, (MPa) | 380 min |
| Yield Strength, (MPa) | 205 min |
| Elongation min. % | 35 |
| Hardness, HB | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and supplier of Carbon Steel A334 GR 8 Tubing in Dubai, UAE. We provide top-quality steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory consists of Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to fast delivery and exceptional customer service, we ensure that all our products are made from the finest raw materials, guaranteeing superior strength, durability, and performance for demanding industrial applications. Get in touch with us today for your Carbon Steel A334 GR 8 Tubing requirements!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
The tube is used in cryogenic piping systems, heat exchangers, and condensers where resistance to low temperature is essential. The tube is also used in pressure vessels for cryogenic service, refrigeration systems, and equipment utilized in the transportation of refrigerants. Its durability in cold environments makes it ideal for applications in the chemical and petrochemical industries, as well as in power generation and oil and gas pipelines.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
