Bhavesh Steel is a prominent supplier and manufacturer of Carbon Steel API X52 5L PSL 2 Pipes in Dubai, UAE. With its robust presence in the steel market, the company delivers superior piping products that are compliant with international standards. Renowned for reliability, strength, and outstanding performance, these pipes are designed to satisfy the stringent requirements of diverse industrial applications. Bhavesh Steel is dedicated to quality through sophisticated manufacturing techniques, rigorous quality control, and speedy delivery. With services for clients in the UAE and other countries, the company is a reliable ally across industries like oil and gas, petrochemicals, and infrastructure.
Carbon Steel API X52 5L PSL 2 Pipes are produced using a purified blend of carbon, manganese, phosphorus, sulfur, and trace amounts of alloying elements to provide maximum strength and performance. These pipes provide a minimum yield strength of 52,000 psi and tensile strength of 66,000 to 110,000 psi. They are recognized for excellent notch toughness, weldability, and low carbon content, which ensures enhanced corrosion resistance. The exact mechanical and chemical proportion in PSL 2 pipes provides uniform quality, with which they find application in high-pressure and long-lasting demanding processes.
| Grade of material | X52 / L390 (N, M, Q, R) |
| X52 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Standard | ISO 3183 L390/ API 5L X52 |
| API 5L X52 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X52 SAW | 16″ – 100″ NB |
| API 5L X52 PSL2 ERW and HFW | 1/2” NB – 24” NB |
| API 5L X52 PSL2 Pipe end | Square Cut, Chamfering, Grooved, Buttweld, Thread Cutting, Squared Ends, Deburring, Flanged Ends, Beveled End (BE), Socket, Cut Grooves, Vibrator Grinding, Coupling, Plain end (PE), Threaded Ends (Male & Female), Pub Joints, Screwed |
| Origin of X52 material | European, Chinese, Africa, Gulf, Asian, UAE, Russian, American, Japan, UAEraine, Japanese, Indian, USA, Latin-American, Korean, |
| API 5L X52 Wall Thickness | SCH-STD, SCH160, SCH-XXS, SCH40, SCH-XS, SCH80 |
| Equivalent Standards | JIS, ANSI, EN, DIN, IS, UNI, ISO, AWWA, SS, AISI, NFA, BS, GOST, SA, KS, API, C ASTM, SAE, GB, |
| PSL Level | |
| Coating for API 5L X52 Line Pipe | Galvanized, 3PP, Varnished, 3LPE, lined pipe, Black Painting, 3PE, CRA clad, FBE, Anti-Rust Oil |
| Carbon Steel Grade | Mass fraction, % based on heat and product analyses | Carbon Equiv a | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| C | Si | Mn | P | S | V | Nb | Ti | Other | CE IIW | CE Pcm | |||||||||||
| max b | max | max b | max | max | max | max | max | max | max | ||||||||||||
| X52N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.1 | 0.05 | 0.04 | d,e,l | 0.43 | 0.25 | ||||||||||
| Pipe Grade | Tensile Properties – Pipe Body of SMLS and Welded Pipes PSL 2 | Seam of Welded Pipe | |||||
|---|---|---|---|---|---|---|---|
| Yield Strength a | Tensile Strength a | Ratio a,c | Elongation | Tensile Strength d | |||
| Rt0,5 PSI Min | Rm PSI Min | R10,5IRm | (in 2in) | Rm (psi) | |||
| Af % | |||||||
| Minimum | Maximum | Minimum | Maximum | Maximum | Minimum | Minimum | |
| X52 | 52,200 | 76,900 | 66,700 | 110,200 | 0.93 | f | 66,700 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| API 5L X52 Pipe types | API 5L X52 Pipe Size (mm) | Tolerances | |
|---|---|---|---|
| Hot rolled API 5L X52 Seamless Pipe | OD | <50 | ±0.50mm |
| ≥50 | ±1% | ||
| WT | <4 | ±12.5% | |
| ≥4～20 | +15%, -12.5% | ||
| >20 | ±12.5% | ||
| Cold drawn API 5L X52 Seamless Pipe | OD | 6～10 | ±0.20mm |
| 10～30 | ±0.40mm | ||
| 30～50 | ±0.45 | ||
| >50 | ±1% | ||
| WT | <1 | ±0.15mm | |
| >1～3 | + 15%, – 10% | ||
| >3 | + 12.5%, – 10% | ||
Bhavesh Steel is a leading supplier of high-quality Carbon Steel API X52 5L PSL 2 Pipes products in Dubai, UAE. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
These pipes are frequently utilized to transport natural gas, crude oil, and refined petroleum products over long distances in the oil and gas industry. They are also used for use in offshore platforms, refineries, petrochemical plants, and structural projects that require high-performance materials. Their outstanding mechanical properties and pressure resistance, temperature variation resistance, and corrosive environments resistance make them suitable for water transmission systems and essential mechanical applications. The strength and flexibility of Carbon Steel API X52 5L PSL 2 Pipes render it the first choice for industries that need trouble-free and durable pipeline solutions.
