Bhavesh Steel is a prominent manufacturer and supplier of Carbon Steel DIN 1629 pipes in Dubai, UAE. With expertise in high-quality seamless and welded pipes, the company serves various industries that demand reliable and durable piping solutions. With an adherence to excellence, Bhavesh Steel offers products that live up to the highest international standards, offering clients reliable materials for their projects. With their large inventory and prompt delivery services, they are a business-friendly partner for companies in the area.
Carbon Steel DIN 1629 pipes, namely grades St37.0, St44.0, and St52.0, are typified by different carbon content and mechanical properties. Grade St37.0 contains a maximum of 0.17% carbon, with minimum yield strength of 235 MPa and tensile strength of 350 to 480 MPa. Grade St44.0 has a maximum of 0.21% carbon, with minimum yield strength of 275 MPa and tensile strength of 420 to 550 MPa. Grade St52.0 contains up to 0.22% carbon content, with at least 355 MPa yield strength and tensile strength of 500 to 650 MPa. These differences ensure that every grade is applicable for other uses depending on the strength needs. Sunny Steel
| Standard | DIN 1629 |
| Grade | ST52 |
| Size in MM | 4 To 190 x Wall Thickness 0.5 To 15 |
| Outer Dimensions in MM | 4 To 60 |
| Wall Thickness in MM | 0.5 To 8 |
| Schedule | Schedule XS, Schedule 160, Schedule 40, Schedule XXS, Schedule 80 Supplier and Manufacturer |
|---|---|
| Length in MM | 6000 |
| Pipe Marking | All Pipe are marked as follows: Supplier or Manufacturer’s Name, Standard, Grade, OD, Thickness, Length, Heat Number |
| St37.0 | 1.0254 | 0.17 | 0.040 | 0.040 | 0.009²) |
| St44.0 | 1.0255 | 0.21 | 0.040 | 0.040 | 0.009²) |
| St52.0³) | 1.0421 | 0.22 | 0.040 | 0.035 | – |
| Steel Grade | Upper Yield Stress ReH for wall thickness, in mm, | Tensile strength Rm N/mm² | Elongation(%) A5 | ||||
|---|---|---|---|---|---|---|---|
| Symbol | Material Number | up to 16 | over 16 up to 40 | over 40 up to 65 | Longitudinal | Transverse | |
| St 37.0 | 1.0254 | 235 | 225 | 216 | 350²) to 480 | 25 | 23 |
| St 44.0 | 1.0256 | 275¹) | 265¹) | 255¹) | 420²) to 550 | 21 | 19 |
| St 52.0 | 1.0421 | 355 | 345 | 335 | 500²) to 650 | 21 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Execution | Size Range | OD Tolerance | Wall tolerance |
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Jaxon Steel is a leading manufacturer and supplier of high-quality Carbon Steel DIN 1629 Pipe products in Dubai, UAE. Specializing in steel solutions, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product lineup includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Renowned for our reliable delivery and exceptional customer service, we are committed to providing top-grade steel materials that ensure durability and performance in various industrial applications. Jaxon Steel is your trusted partner for all your Carbon Steel DIN 1629 Pipe needs.
In construction, they are used as building and bridge structural materials. They are used in the auto industry for the production of chassis as well as other essential components. In the oil and gas industry, the pipes are a part of pipeline networks, and they are used to transport fluids with safety. They are used in the production of equipment and machinery as well as in making heat exchangers, showing how versatile and reliable they are in harsh conditions. Sources
