Bhavesh Steel is a prominent producer and distributor of Carbon Steel DIN 17172 pipes in Dubai, UAE. The company deals in superior quality seamless and welded pipes and has clients from numerous industries that demand consistent and long-lasting piping solutions. With excellence as a pursuit, Bhavesh Steel makes sure that all of its products conform to stringent international standards, allowing clients to have reliable materials for their projects. With its broad inventory and prompt delivery services, it is a reliable business partner for companies in the area.
Carbon Steel DIN 17172 tubes, Grade StE 210.7, have a maximum carbon level of 0.17%, making them more weldable and formable. The standard chemical content is 0.35% of manganese, 0.35% of silicon, along with trace amounts of phosphorus (0.040%) and sulfur (0.040%), that further make them ductile and easy to fabricate. Mechanically, these pipes have a yield strength of 210 MPa and tensile strength of between 350 MPa, with minimum elongation in the longitudinal direction being 22%, keeping them strong under tension.
| Standards | DIN 17172 StE 360.7 Pipe |
|---|---|
| Welded Pipe Size | 5.0 mm – 1219.2 mm |
| Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| EFW Pipe size | 5.0 mm – 1219.2 mm |
| Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| We can also cut, thread, and groove Tubes to meet your specifications | |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.22 | max 0.55 | 0.90 – 1.50 | 0.04 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 630 | – | – | 20 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and supplier of high-quality Carbon Steel DIN 17172 Pipe products in Dubai, UAE. Specializing in premium steel solutions, we offer a wide range of materials, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong reputation for reliable delivery and exceptional customer service, we are committed to providing top-grade steel materials that ensure durability and superior performance across various industrial applications. Jaxon Steel is your trusted partner for all Carbon Steel DIN 17172 Pipe requirements.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | #ERROR! | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | #ERROR! | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel DIN 17172 pipes find major usage in most industries because of their strength and versatility. In the construction industry, they are used as structural elements in buildings and bridges. The automobile industry utilizes them for the production of chassis and other essential components. In the oil and gas industry, these pipes are a crucial part of pipeline systems, enabling the transportation of fluids safely. They also get utilized in manufacturing machines, equipment, and in the fabrication of heat exchangers, showcasing their durability and versatility in challenging applications.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
