Bhavesh Steel is a leading manufacturer and supplier of Carbon Steel EN 10210-1 Grade S355JOH Pipes in Dubai, UAE. Bhavesh Steel is known for its focus on quality, precision, and customer satisfaction. Bhavesh Steel supplies strong and reliable steel piping solutions as per different industrial requirements. Our pipes of Carbon Steel S355JOH adhere to European standards and are designed to meet the demands of structural applications that call for strength, toughness, and resilience against severe conditions. Having a solid base in the Middle East, we serve industries like construction, infrastructure, oil & gas, and energy with outstanding product performance.
Carbon Steel EN 10210-1 Grade S355JOH Pipe is a low-alloy structural steel that has high strength and fine weldability. It generally consists of carbon (≤ 0.22%), manganese (≤ 1.6%), phosphorus (≤ 0.035%), and sulfur (≤ 0.035%). This grade has a minimum yield strength of 355 MPa and tensile strength of 470–630 MPa. The grade is impact tested at -20°C, which guarantees toughness at low temperatures. Its mechanical properties qualify it for load-bearing structures and dynamically stressed components in numerous demanding applications.
Standard : BS EN 10210 – Hot finished structural hollow sections of non-alloy and fine grain steels
Grade : S355J0H
SHS (Square Hollow Sections) Sizes : 20*20mm-400*400mm
Wall Thickness : 0.5mm – 25mm
Length : 6000-14000 mm
Type : Seamless/ Welded / ERW
Dimensional Tolerances : Thickness : (All sizes +/- 10%)
Dimension Range : 21.3-914mm
Packing : In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark
Surface Protection : Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized
| Steel Grade | % by mass maximum | |||||||
| Steel Name | Steel Number | C specified thickness (mm) | Si | Mn | P | S | N | |
| <_40 | > 40 <_ 120 | |||||||
| S355J0H | 1.0547 | 0.22 | 0.22 | 0.55 | 1.60 | 0.035 | 0.035 | 0.009 |
| Steel Grade | Minimum yield strength eH Mpa | Minimum tensile strength Rm Mpa | ||||||||
| Steel Name | Steel Number | Specified thickness in mm | Specified thickness in mm | |||||||
| <_16 | >16 <_40 | >40 <_63 | >63 <_ 80 | >80 <_100 | >100 <_120 | <_3 | >100 <_ 120 | |||
| S355J0H | 1.0547 | 355 | 345 | 335 | 325 | 315 | 295 | 510-680 | 470-630 | 450-600 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10210-1 Grade S355JOH Pipe in Dubai, UAE. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to reliable delivery and exceptional customer service, Jaxon Steel provides top-grade materials that ensure superior performance in various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10210-1 Grade S355JOH Pipe needs.
| DIN | EN | BS | NFA | ASTM | ASME |
| – | EN 10210-1 Grade S355JOH | – | – | – | – |
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
