Jaxon Steel Ltd is a UAE-based midlands leading manufacturer and supplier of high quality carbon steel products. Maintaining accuracy and reliability as our main factor, we provide the widest variety of carbon steels, including the EN 10216-4 pipes. It is their durability that makes them perfect for various industrial purposes such as pressure vessels and power plants. The products at Jaxon Steel are produced to international standards. This guarantees the clients have high performance with excellent value for money in the projects.
Carbon Steel EN 10216-4 pipes are made up of carbon, with small percentages of manganese, silicon, sulfur, and phosphorus. The composition is typically carbon (0.10-0.22%), manganese (0.30-0.60%), and silicon (0.10-0.35%). These pipes have excellent mechanical properties, such as tensile strength of 490-700 MPa, yield strength of minimum 205 MPa, and elongation of 22% (min). Pipes have good strength, toughness and wear and corrosion resistance, meaning that they will find applications even at high-pressure operations. Some of the large applications of the EN 10216-4 pipes include; Petrochemical applications Power generation plants Oil & Gas.
| Steel Grade | Steel No. | C max. | Si max. | Mn | P max. | S max. | Cr max. | Mo max. | Ni max. | Al max. | Cu max. | N max. | Nb max. | Ti max. | V max. | Nb+Ti+V max. |
| P275NL1 | 1.0488 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,02 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| P275NL2 | 1.1104 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,015 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | 650 | – | 22 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10216-4 Pipe products in Dubai, UAE. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel provides top-grade materials that deliver outstanding performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10216-4 Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel EN 10216-4 pipes are widely used for high-pressure and high-temperature applications because of their strength and durability. It is also very commonly used in the petrochemical, power generation, and oil & gas industries to transport fluids and gases in very adverse conditions. Pressure vessels, boilers, heat exchangers, and industrial piping systems are other applications of the pipes. Their excellent mechanical properties make them suitable for applications requiring resistance to stress, corrosion, and wear. Additionally, EN 10216-4 pipes are used in construction, manufacturing, and automotive sectors, providing reliable performance in demanding conditions.
