Bhavesh Steel is a prominent producer and distributor of Carbon Steel F70 Forged Fittings in Dubai, UAE. Focused on providing top-grade forged fittings, the company supplies numerous industries that need good quality piping solutions. With dedication to excellence, Bhavesh Steel makes sure that all its products are of high international standards, and their clients receive reliable materials for their projects. Their complete inventory and prompt delivery services are why businesses in the region trust them.
Carbon Steel F70 Forged Fittings consist of carbon, manganese, silicon, phosphorus, sulfur, chromium, and molybdenum. These fittings have a 485 MPa yield strength and 565 MPa tensile strength, with an 18% minimum elongation. The hardness ranges from 197 to 237 Brinell, showing good wear resistance. These mechanical properties guarantee the fittings’ resistance to high-pressure and high-temperature conditions and thus for it to be used in tough applications.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F70 | 0.06-0.10 | 0.20-0.40 | 1.10-1.40 | ≤ 0.020 | ≤ 0.010 | 1.20-1.70 | 0.20-0.40 | ≤ 0.30 | ≤ 0.25 | 0.02-0.06 | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 70 | 82 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F70 Forged Screwed Elbows, Street Elbow, Carbon Steel F70 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F70 Reducing Coupling, Carbon Steel F70 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F70 Threaded Bushing, Carbon Steel F70 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F70 Barrel Nipples, CS F70 Forged Threaded Boss, Carbon Steel F70 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F70 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F70 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F70 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F70 Coupling |
Carbon Steel F70 Forged Fittings are widely used in most industries because they are strong and can be used for multiple purposes. In the oil and gas industry, they are used in high-pressure fluid-transporting pipeline systems. They are used in steam and water lines by the power generation industry. They find their application in reactor and heat exchanger systems in chemical processing. Also, they are utilized in building construction for scaffolding and structural supports, thereby showing their versatility and strength in extreme conditions.
