Founded in 1995 and having its headquarters in Dubai, UAE, Bhavesh Steel is a prominent producer and supplier of carbon steel JIS G3456 pipes of high quality. The seamless alloy steel tubes are designed with a view to perform optimally at high temperatures in the form of boilers, heat exchangers, and superheaters. Bhavesh Steel JIS G3456 Pipes are made with a firm commitment towards quality so that every pipe produced meets up to the highest international standards, providing customers with long-lasting and reliable solutions for their industrial needs. With a strong distribution network and a good reputation, Bhavesh Steel remains a reliable partner in the steel business.
Carbon steel JIS G3456 tubes consist mainly of carbon, manganese, phosphorus, sulfur, silicon, chromium, and molybdenum. The carbon content is usually up to 0.20%, and manganese content between 0.30% and 0.80%. Phosphorus and sulfur contents are minimized, usually below 0.035%, in order to improve weldability and minimize brittleness. Its mechanical properties are tensile strengths of 380 MPa, yield strengths of 205 MPa, and elongation percentages of 30%, depending on grade. It is manufactured to accommodate high-temperature conditions and best suited for heat transfer applications.
| Standards | JIS G3456 Carbon Steel Pipe |
|---|---|
| JIS G3456 Carbon Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| JIS G3456 Carbon Steel Welded Pipe Size | 5.0 mm – 1219.2 mm |
| JIS G3456 Carbon Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| JIS G3456 Carbon Steel Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| JIS G3456 Carbon Steel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| JIS G3456 Carbon Steel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All JIS G3456 Carbon Steel Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Grade | C | Si | Mn | P | S |
| JIS G3456 STPT370 | ≤ 0.25 | 0.10-0.35 | 0.30-0.90 | ≤ 0.035 | ≤ 0.035 |
| JIS G3456 STPT410 | ≤ 0.30 | 0.10-0.35 | 0.30-1.00 | ≤ 0.035 | ≤ 0.035 |
| JIS G3456 STPT480 | ≤ 0.33 | 0.10-0.35 | 0.30-1.00 | ≤ 0.035 | ≤ 0.035 |
| Grade | Tensile Property (N/mm2) | Yield Point or Yield Strength (N/mm2) | Elongation (%) | |||
| NO. 11 Sample; NO. 12 Sample | NO. 5 Sample | NO. 4 Sample | ||||
| Longitudinal | Transverse | Longitudinal | Transverse | |||
| JIS G3456 STPT370 | ≥ 370 | ≥ 215 | ≥ 30 | ≥ 25 | ≥ 28 | ≥ 23 |
| JIS G3456 STPT410 | ≥ 410 | ≥ 245 | ≥ 25 | ≥ 20 | ≥ 24 | ≥ 19 |
| JIS G3456 STPT480 | ≥ 480 | ≥ 275 | ≥ 25 | ≥ 20 | ≥ 22 | ≥ 17 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is one of the prominent manufacturers and suppliers of high-quality Carbon Steel JIS G3456 Pipe in Dubai, UAE. Being a company of premium steel material, we have a comprehensive product range in the form of Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our wide inventory list consists of Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With commitments to time-to-market delivery and high quality of customer service, Jaxon Steel assures to deliver high-quality raw materials for better performance in any demanding industrial applications. Contact us today at Jaxon Steel to order all of your Carbon Steel JIS G3456 Pipe needs.
| Type | Allowable Deviation of Outer Diameter | Allowable Deviation of Wall Thickness | |||
| Hot-Working Seamless Steel Pipe | ＜50 mm | ± 0.5 mm | ＜ 4 mm ≥ 4mm | ± 0.5 mm ±12.5% | ≤ 20% of thickness |
| ≥ 50mm~＜160mm | ± 1% | ||||
| ≥ 160mm~≤ 200 mm | ± 1.6 mm | ||||
| ≥ 200 mm | ± 0.8% | ||||
| For ≥350 mm ones, we can measure according to the perimeters. Allowable deviation is ± 0.5%. | |||||
| Cold-Working Steel Seamless Pipe and Electric-Resistance Welded(ERW) Steel Pipe | ≤ 40 mm | ± 0.03 mm | ＜ 2 mm ≥ 2 mm | ± 0.2 mm ± 10 | |
Carbon steel JIS G3456 pipes are used extensively across different industries because of their superior strength and heat transfer properties. In the power generation industry, these pipes are used in superheaters, economizers, and boilers for efficient heat transfer and enhancing energy efficiency. They are also used in fossil fuel stations and steam-generating facilities for their capacity to endure high pressure and temperature. JIS G3456 pipes are also used in refineries and petrochemical processing plants for their durability under harsh environments.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
