Bhavesh Steel stands out as a top manufacturer and supplier of EN 9 Sheets and Plates in Dubai, UAE. They’re well-known for providing high-quality carbon steel products that cater to a variety of industrial needs. With a strong focus on quality, precision, and customer satisfaction, Bhavesh Steel ensures that their EN 9 steel sheets and plates comply with international standards. Supported by cutting-edge infrastructure and a team of skilled professionals, they deliver robust, high-performance steel solutions for the automotive, engineering, and construction sectors. Their products are recognized for their strength, reliability, and excellent machinability, making Bhavesh Steel a go-to choice not just in the UAE, but also in global markets.
EN 9 Sheets and Plates are made from medium carbon steel, containing around 0.50–0.60% carbon and 0.50–0.80% manganese, which gives them a great balance of strength and wear resistance. These plates boast impressive tensile strength, typically between 600–800 MPa, along with good hardness and moderate ductility. EN 9 steel is perfect for heat treatment processes like hardening and tempering, which boost its mechanical performance. It also offers good machinability when normalized or annealed. These characteristics make EN 9 steel sheets and plates ideal for applications that require strength, toughness, and precision under significant mechanical stress.
Grade : EN9 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
| BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| 070M55 | EN9 | 1055 | 1.0535 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find EN 9 Sheets and Plates widely used in industries that need durable and wear-resistant materials. In the automotive field, they’re used to make shafts, gears, crankshafts, and axles. In engineering, they’re found in spindles, couplings, and heavy-duty fasteners. Thanks to their excellent hardness and toughness after heat treatment, they’re also perfect for industrial tools, machinery components, and structural parts that face repetitive stress. EN 9 is a popular choice in agricultural and mining equipment due to its durability. Its versatility and mechanical reliability make it a favored material for high-performance and load-bearing applications.
