Bhavesh Steel has earned a solid reputation in Dubai, UAE, for manufacturing and supplying top-notch EN10305-1 and EN10305-4 seamless tubing. We pride ourselves on our unwavering commitment to precision, durability, and adherence to international standards, catering to the varied needs of industries throughout the region. Our seamless tubes are designed to perform exceptionally well in high-pressure and critical environments. With years of experience, cutting-edge technology, and a focus on customer satisfaction, Bhavesh Steel guarantees timely deliveries and competitive pricing, making us the go-to partner for seamless tubing solutions in the UAE and beyond.
Our EN10305-1 and EN10305-4 seamless tubes are crafted from high-quality low carbon steel, primarily using grades like E235 and E355. These tubes are known for their impressive dimensional accuracy and smooth internal surfaces. Depending on the grade, they boast mechanical properties such as a tensile strength ranging from 340 to 640 MPa and a yield strength between 235 and 355 MPa. They also provide good elongation, excellent machinability, and remarkable formability. Processes like cold drawing and normalization further enhance the tubes’ strength and durability, making them perfect for applications that demand precision and reliability.
| Steel Name | Steel Number | C max. | Si max. | Mn max. | P max. | S max. | AL min. |
| E215 | 1.0212 | 0.10 | 0.05 | 0.7 | 0.025 | 0.025 | 0.025 |
| 1.0308 | 0.17 | 0.35 | 1.2 | 0.025 | 0.025 | / | |
| E355 | 1.058 | 0.22 | 0.55 | 1.6 | 0.025 | 0.025 | / |
| Mechanical properties at room temperature | |||||||||||||
| Steel Grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Number | +C | +LC | +SR | +A | +N | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290 to 430 | 25 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340 to 480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 | 450 | 22 | 490 to 630 | 355 | 22 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality EN10305-1 / EN10305-4 Seamless Tubing in Dubai, UAE. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior precision, strength, and durability for demanding industrial applications. Contact us today for all your EN10305-1 / EN10305-4 Seamless Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
You’ll find EN10305-1 and EN10305-4 seamless tubing widely utilized across various industries, thanks to their high dimensional accuracy and superior surface finish. Common uses include hydraulic and pneumatic systems, automotive components, mechanical engineering, and construction equipment. In the automotive industry, these tubes are essential for fuel lines, brake systems, and steering components. They’re also ideal for manufacturing precision instruments and HVAC systems. Their outstanding performance under pressure and ability to maintain integrity in challenging environments make them the perfect choice for both industrial and commercial applications where precision and reliability are paramount.
