Bhavesh Steel, having been founded in 1995 and being a Dubai, UAE-headquartered company, is a prominent manufacturer and supplier of high-grade FORA 500 wear-resistant steel plates. These steel plates are designed to be extremely resistant to abrasive conditions and are suitable for use in industries like mining, construction, and heavy machinery. The quality commitment of Bhavesh Steel guarantees that every FORA 500 plate is held to high international standards, delivering clients with long-lasting and dependable solutions for their wear-resistant requirements. The extensive inventory and timely delivery services offered by the company further establish it as a go-to company in the steel business.
FORA 500 wear-resistant steel plates consist of a low-alloyed steel with a maximum carbon content of 0.30%. The major alloying elements are manganese (max. 1.60%), silicon (max. 0.70%), chromium (max. 2.00%), nickel (max. 0.60%), and molybdenum (max. 0.60%). These elements promote the steel’s hardness and wear resistance. Mechanical properties are a Brinell hardness of 460–540 HB, yield strength of about 1350 MPa, tensile strength of 1700 MPa, and elongation of around 10%. These properties suit FORA 500 plates for high-impact and abrasive applications.
Item : Fora 500
Thickness : 5mm to 150mm
Width : 1,500mm to 2,500mm
Length : 1000-12000mm
Heat Treatment : N, Q+T
Surface Paint : EP, PE, HDP, SMP, PVDF
| Plate | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| THICKNESS MM | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | TYPV | TYPV |
| 4-13 | 0.27 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 0.25 | 0.25 | 0.004 | 0.49 | 0.34 |
| (13) -32 | 0.29 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 0.50 | 0.30 | 0.004 | 0.62 | 0.41 |
| (32) -40 | 0.29 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 1.00 | 0.60 | 0.004 | 0.64 | 0.43 |
| (40) -80 | 0.30 | 0.7 | 1.6 | 0.025 | 0.01 | 1.50 | 1.50 | 0.60 | 0.004 | 0.74 | 0.46 |
| Thickness | Hardness HBW | Typical yield strength MPa, |
| mm | (min – max 1) | not guaranteed |
| 4 – 32 | 470 – 530 | 1250 |
| (32) – 103 | 450 – 540 | 1250 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
FORA 500 wear-resistant steel plates are heavily applied in industries where materials are expected to handle high wear and impact. In mining, they find application in crusher liners and chutes. They find application in the construction industry in dump truck bodies and excavator buckets. FORA 500 plates are also a part of making heavy-duty machinery such as bulldozer blades and conveyor systems. Their high hardness and toughness provide durability and reliability in applications exposed to rough conditions, thus lowering the cost of maintenance and improving operation efficiency.
