Bhavesh Steel, founded in 1995 and with its headquarters in Dubai, UAE, is a prime manufacturer and supplier of high-grade HB 400 wear-resistant steel plates. Famed for remarkable durability and performance, the plates are commonly employed in industries like mining, construction, and heavy machinery. Bhavesh Steel’s dedication to quality guarantees that every HB 400 plate is held to high international standards, offering customers dependable solutions for harsh applications. With a strong distribution channel and reputation for excellence, Bhavesh Steel remains a go-to partner for enterprises requiring superior wear-resistant materials.
HB 400 wear-resistant steel plates consist of low-alloyed steel having a content of carbon between 0.25% and 0.30%. The principal alloying elements are manganese up to 1.60%, silicon up to 0.70%, chromium up to 1.50%, nickel up to 0.50%, and molybdenum up to 0.50%. These elements improve the hardness and wear resistance of the steel. Mechanical properties consist of 370–430 HBW Brinell hardness, yield strength of about 800 MPa, tensile strength ranging from 1000–1250 MPa, and elongation of around 10%. All these properties render HB 400 plates ideal for hard impact and abrasive conditions.
Width:Â 500-3000mm
Thickness :Â 3-130mm
Length:Â 1000-12000mm
Heat Treatment:Â N, Q+T
Surface Paint:Â EP, PE, HDP, SMP, PVDF
| Hardened 400 Chemical Composition (%) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Plate | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| thickness mm | max % | max % | max % | max % | max % | max % | max % | max % | max % | typv | typv |
| 3- 6 | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.50 | 0.25 | 0.25 | 0.004 | 0.41 | 0.28 |
| 3-（8） | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.30 | 0.25 | 0.25 | 0.004 | 0.33 | 0.23 |
| 8 – 20 | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.50 | 0.25 | 0.25 | 0.004 | 0.37 | 0.27 |
| （20）-32 | 0.18 | 0.70 | 1.60 | 0.025 | 0.01 | 1.00 | 0.25 | 0.25 | 0.004 | 0.48 | 0.29 |
| （32）-45 | 0.22 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 0.50 | 0.60 | 0.004 | 0.57 | 0.31 |
| （45）-51 | 0.22 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 0.50 | 0.60 | 0.004 | 0.57 | 0.38 |
| （51）-80 | 0.27 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 1.00 | 0.60 | 0.004 | 0.65 | 0.41 |
| （80）-130 | 0.32 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 1.50 | 0.60 | 0.004 | 0.73 | 0.48 |
| Mechanical properties of Hardened 400 | |||||
|---|---|---|---|---|---|
| Grade | Mechanical Property | Charpy V Impact Test | |||
| HARDOX 400 | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -40 | J | |
| 1000 | 1250 | 10 | 45 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Thickness (mm) | Product | Hardness Range (HBW) |
|---|---|---|
| 2.5 – 6.4 | Cut Lengths | 360 – 420 |
| 5 – 15 | Heavy Plates | 360 – 420 |
| 15- 30 | Heavy Plates | 360 – 450 |
| 30 – 60 | Heavy Plates | 360 – 480 |
HB 400 wear plates find wide usage in industries that need materials capable of withstanding severe wear and impact. They find application in mining for crusher liners and chutes. They are used by the construction industry for dump truck bodies and excavator buckets. HB 400 plates play an essential role in the production of heavy-duty machinery such as bulldozer blades and conveyor systems. Their higher hardness and toughness provide them with durability and reliability for long-term use in working conditions with high severity, thus lowering maintenance costs and promoting efficiency in operations.
