Bhavesh Steel is a reputable manufacturer and supplier located in Dubai, UAE, specializing in high-quality NACE MR 0103/0175 HIC Boiler Sheets and Plates. Renowned for their commitment to quality and reliability, the company caters to essential industries like oil, gas, petrochemical, and power generation. These plates are expertly crafted to withstand hydrogen-induced cracking (HIC) and comply with the rigorous standards set by NACE. With a strong focus on customer satisfaction, Bhavesh Steel provides corrosion-resistant steel solutions that guarantee safety, durability, and long-lasting performance even in the toughest and most corrosive environments.
The NACE MR 0103/0175 HIC Boiler Sheets and Plates are made from a blend of carbon, manganese, silicon, phosphorus, sulfur, and alloying elements such as chromium, molybdenum, and nickel to boost their strength and resistance. These plates exhibit impressive tensile and yield strength, along with excellent ductility and impact resistance, fulfilling the demanding mechanical property criteria outlined by NACE standards. Their low sulfur content and fine grain structure significantly reduce the risk of hydrogen-induced cracking, making them a reliable choice for applications in the harsh sour service conditions typical in the oil and gas sector.
Grade : ASME SA 516 GR.70N Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : 52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service.
Process of Manufacturing : Hot-Rolled (HR)
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Yield strength (ksi) | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 485-620 (70-90) | 260 (38) | 17 | 21 |
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-490A/B | EN10028 P355GH | A/SA516 – Grade 70 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These boiler sheets and plates find use in a variety of industrial applications that require resistance to sour gas corrosion and hydrogen-induced cracking. They are commonly utilized in pressure vessels, heat exchangers, boilers, storage tanks, and process piping within oil refineries, gas processing facilities, and petrochemical plants. Their sturdy construction and compliance with NACE MR 0103/0175 specifications make them ideal for challenging environments that contain hydrogen sulfide (H₂S). Whether for offshore platforms or onshore processing units, these plates ensure dependable performance, safety, and structural integrity in critical high-pressure and corrosive service conditions.
