In Dubai, United Arab Emirates, Bhavesh Steel is a well-known producer and supplier of SA 516 Grade 70 Sheets and Plates, providing high-grade boiler and pressure vessel steel to satisfy vital industry needs. SA 516 Grade 70 is extensively utilised in sectors like power generation, petrochemicals, and oil and gas because of its reputation for resilience and excellent performance in harsh environments. Delivering certified, tested materials that meet ASTM standards is our main priority at Bhavesh Steel. We are a reliable steel partner in the United Arab Emirates and the Middle East because of our dedication to quality, timely delivery, and customer satisfaction.
Grade 70 SA 516 Carbon steel sheets and plates are made of carbon (0.27–0.31%), manganese (0.79–1.30%), phosphorus (maximum 0.035%), and sulphur (maximum 0.035%). Excellent tensile strength (485–620 MPa) and a minimum yield strength of 260 MPa are provided by these plates. They work well at moderate and lower temperatures and have outstanding notch toughness. In order to increase its ductility and resistance to brittle fracture, the steel is frequently supplied in a normalised state. Additionally, SA 516 Gr 70 has excellent weldability, which makes it perfect for creating intricate pressure-containing machinery.
Grade :Â ASME SA 516 GR.65 Boiler and Pressure Vessel Steel Plates
Width :Â 1250mm-3000mm
Thickness : 3 – 200 mm/ dimensions up to 4.000 mm
Length :Â 3000mm-11000mm.
Production :Â Hot-Rolled (HR)
Heat Treatment :Â Rolled/Normalised/N+T/QT
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Boilers, storage tanks, heat exchangers, and pressure vessels are all frequently built using SA 516 Grade 70 Sheets and Plates. In sectors like chemical manufacturing, thermal power generation, gas processing, and oil refining, these elements are crucial. The material functions dependably under high pressure and fluctuating temperatures because of its exceptional toughness and high tensile strength. Applications requiring high weldability and structural integrity also favour it. SA 516 Gr 70 plates are an essential component for pressure-bound machinery and structural steel fabrication because they guarantee durability and safety in crucial operations.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
